| PartNumber | LTP500GV-F01 |
| Marca | Samsung |
| mărimea | 5.0 |
| Aplicație | PDA |
| Rezoluţie | 480×640 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 250:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SAMSUNG |
| model de panou | LTP500GV-F01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 480(RGB)×640 , VGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 75.6×100.8 mm |
| contur | 83.84×113.2×4.8 mm |
| suprafaţă | |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 250:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193140% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 40/30/50/50 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S4PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/8.0/16.0/-8.4V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplicarea | PDA |
