| PartNumber | TM050NDH01 |
| Marca | Tianma |
| mărimea | 5.0 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 280 |
| CR | 450:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | TIANMA |
| model de panou | TM050NDH01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 110.88×62.832 mm |
| suprafaţă | Antiglare |
| luminozitatea | 280 cd/m² (Typ.) |
| Raport de contrast | 450:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 45 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PND |
| LTE052T-4301-1 | TPO | 5.0 | 320×234 |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| TM050QDH01 | Tianma | 5.0 | 640×480 |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
| TM050QDH07 | Tianma | 5.0 | 640×480 |
| TM050QDH11 | Tianma | 5.0 | 640×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
| 43WQW1H | SII | 4.3 | 480×272 |
| 43WVF1G | SII | 4.3 | 800×480 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS480KC02 | Samsung | 4.8 | 800×480 |
| LMS500HF13-002 | Samsung | 5.0 | 480×272 |
| LQ043T1DG01 | SHARP | 4.3 | 480×272 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| LR430RC9001 | Innolux | 4.3 | 480×272 |
| NL4827HC19-01B | NLT | 4.3 | 480×272 |
