| PartNumber | TM050LDZ00 |
| Marca | Tianma |
| mărimea | 5.0 |
| Aplicație | CNS |
| Rezoluţie | 240×400 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 200:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | TIANMA |
| model de panou | TM050LDZ00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 240(RGB)×400 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 65.16×108.6 mm |
| contur | 76.3×123.4×12.9 mm |
| suprafaţă | Antiglare |
| luminozitatea | 400 cd/m² (Min.) |
| Raport de contrast | 200:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193170% |
| timp de raspuns | 40 (Max.)(Tr+Td) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 1S10PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6/8-bit) + SPI, 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
