| PartNumber | LR043JC211 |
| Marca | Innolux |
| mărimea | 4.3 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | ChiHsin |
| model de panou | LR043JC211 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 95.04×53.856 mm |
| contur | 105.5×67.2 mm |
| suprafaţă | Antiglare (Haze 10%) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 16.7M |
| timp de raspuns | 15/35 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.0/5.0V (Typ.)(VCC/VDD) |
| rohs: | |
| aplicarea | PND |
| 43WQW3T | SII | 4.3 | 480×272 |
| G043FTT01.0 | AUO | 4.3 | 480×272 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
| LR043JC111 | Innolux | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| LT043MDY5000 | TOSHIBA | 4.3 | 720×1280 |
| NL4827HC19-01B | NLT | 4.3 | 480×272 |
| 43WQW3H | SII | 4.3 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| HE050NA-01F | Innolux | 5.0 | 800×480 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| LQ043T1DG01 | SHARP | 4.3 | 480×272 |
| LTP400WQ-F01 | Samsung | 4.0 | 480×272 |
| NL4827HC19-01B | NLT | 4.3 | 480×272 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
