| PartNumber | HE050NA-01F |
| Marca | Innolux |
| mărimea | 5.0 |
| Aplicație | PND |
| Rezoluţie | 800×480 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | TTL |
| marca panoului | CHIMEI INNOLUX |
| model de panou | HE050NA-01F |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 108×64.8 mm |
| contur | 115.6×74.38 mm |
| suprafaţă | Antiglare |
| adâncimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 4.66% (Typ.)(with Polarizer) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 50 pins |
| tensiune de intrare | 3.3/10.4/16.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplicarea | PND |
