| PartNumber | PT035TN01 V.6 |
| Marca | Innolux |
| mărimea | 3.5 |
| Aplicație | PND |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 300:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | Parallel/Serial |
| marca panoului | INNOLUX |
| model de panou | PT035TN01 V.6 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, TMR |
| Zonă activă | 70.08×52.56 mm |
| contur | 78.2×65×4.8 mm |
| suprafaţă | Antiglare |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 300 : 1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 15/20 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | Digital RGB (8/24-bit) + SPI, CCIR601/656, 60 pins |
| tensiune de intrare | 3.3/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | PND |
| DLC0350BMG-1 | Other | 3.5 | 240×320 |
| LB035Q02-TD01 | LG Display | 3.5 | 320×240 |
| LH350WV2-SH02 | LG Display | 3.5 | 480×800 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
| PT035TN23 V.1 | Innolux | 3.5 | 320×240 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TMT035DNAFWU19 | Tianma | 3.5 | 320×240 |
| 35QVW1T | SII | 3.5 | 320×240 |
| A043FW02 V8 | AUO | 4.3 | 480×272 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| HSD043I9W1-A01 | HannStar | 4.3 | 480×272 |
| LB035Q01-TJ01 | LG Display | 3.5 | 320×240 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| LR430RC9601 | Innolux | 4.3 | 480×272 |
| LTP400WQ-F01 | Samsung | 4.0 | 480×272 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
