| PartNumber | TMT035DNAFWU19 |
| Marca | Tianma |
| mărimea | 3.5 |
| Aplicație | PND |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 300:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | Serial RGB |
| marca panoului | TIANMA |
| model de panou | TMT035DNAFWU19 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 70.08×52.56 mm |
| contur | 76.9×63.9×3.35 mm |
| suprafaţă | Antiglare |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 10/25 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | Serial RGB (8-bit) + SPI, CCIR601/656, 36 pins |
| tensiune de intrare | 3.3/5.0/15.4/-7.7V (Typ.)(VCC/VDD/VGH/VGL) |
| aplicarea | PND |
| A035QN05 V1 | AUO | 3.5 | 320×240 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| COM35H3M74UTC | ORTUSTECH | 3.5 | 480×640 |
| DLC0350CZG-T-2 | Other | 3.5 | 320×240 |
| LMS350DF03 | Samsung | 3.5 | 320×480 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| PA035XSL | E Ink | 3.5 | 320×234 |
| S035V01 | CDTECH | 3.5 | 480×640 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TMT035DNAFWU19 | Tianma | 3.5 | 320×240 |
| 43WVF0H | SII | 4.3 | 800×480 |
| A043FW02 V0 | AUO | 4.3 | 480×272 |
| DLC0430LZG-6 | Other | 4.3 | 480×272 |
| DLC0500EZG-T-6 | Other | 5.0 | 800×480 |
| LMS500HF01 | Samsung | 5.0 | 480×272 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| P0430WQLC-T | CMEL | 4.3 | 480×272 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
| TS40WD2B-03 | Other | 4.0 | 480×272 |
