| PartNumber | DLC0350BMG-1 |
| Marca | Other |
| mărimea | 3.5 |
| Aplicație | MPH |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 100 |
| CR | 150:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | DLC |
| model de panou | DLC0350BMG-1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 53.64×71.52 mm |
| contur | 64×85×3.13 mm |
| suprafaţă | Hard coating |
| luminozitatea | 100 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.)(Transmissive)6.5:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| tensiune de intrare | 2.8/15/-10V (Typ.)(VCC/VGH/VGL) |
| aplicarea | MPH |
