| PartNumber | LD043WV1-SP01 |
| Marca | LG Display |
| mărimea | 4.3 |
| Aplicație | MPH |
| Rezoluţie | 480×854 |
| Compoziţie | LCM |
| Luminozitate | 440 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | LG Display |
| model de panou | LD043WV1-SP01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480(RGB)×854 , FWVGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 53.568×96.306 mm |
| contur | 59.97×107.31 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 440 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 4S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| tensiune de intrare | 3.0/1.8V (Typ.)(VIC/VDDI) |
| aplicarea | MPH |
| 43WVF1G | SII | 4.3 | 800×480 |
| AMS427GL34-1 | Samsung | 4.3 | 480×800 |
| HSD043I9W1-B00 | HannStar | 4.3 | 480×272 |
| LD043WV1-SP01 | LG Display | 4.3 | 480×854 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T1DH04 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| LTE430WQ-F07 | Samsung | 4.3 | 480×272 |
| AMS369FG03-002 | Samsung | 3.7 | 480×800 |
| AMS470GS16-1 | Samsung | 4.7 | 720×1280 |
| H020HD01 V0 | AUO | 2.0 | 176×220 |
| H027QT01 | AUO | 2.7 | 208×320 |
| LQ020B3DC01 | SHARP | 2.0 | 176×220 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| LTS220QC-F0J | Samsung | 2.2 | 176×220 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
| TM047XDZP02 | Tianma | 4.7 | 540×960 |
