| PartNumber | H027QT01 |
| Marca | AUO |
| mărimea | 2.7 |
| Aplicație | MPH |
| Rezoluţie | 208×320 |
| Compoziţie | LCM |
| Luminozitate | 60 |
| CR | 50:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AU Optronics |
| model de panou | H027QT01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.7 inch |
| rezoluţie | 208(RGB)×320 |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 36.816×56.64 mm |
| contur | 45.8×69.17 mm |
| suprafaţă | |
| luminozitatea | 60 cd/m² (Typ.) |
| Raport de contrast | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 10/30 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 2S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
| aplicarea | MPH |
