| PartNumber | BTL507212-W749L |
| Marca | BOE |
| mărimea | 5.0 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | BOE |
| model de panou | BTL507212-W749L |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| modul de afișare | ADS, Normally Black, Transmissive |
| Zonă activă | 62.1×110.4 mm |
| suprafaţă | |
| luminozitatea | |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 27 pins |
| tensiune de intrare | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| aplicarea | MPH |
