| PartNumber | LQ050T3GG01 |
| Marca | SHARP |
| mărimea | 5.0 |
| Aplicație | PDVD |
| Rezoluţie | 400×234 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 60:1 |
| Culori | Full color |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | SHARP |
| model de panou | LQ050T3GG01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 400(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 111.6×62.9 mm |
| contur | 127.7×80.8×7.6 mm |
| suprafaţă | |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 60:1 (Min.) |
| culorile afișajului | Full color |
| timp de raspuns | 30/50 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | TFT Specific Analog RGB, 32 pins |
| tensiune de intrare | 5.3/10.9/13.0/-10.0V (Typ.)(VSH/VCC/VGH/VGL) |
| aplicarea | PDVD |
