| PartNumber | LQ050T5DW02 |
| Marca | SHARP |
| mărimea | 5.0 |
| Aplicație | CNS |
| Rezoluţie | 400×240 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 1200:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ050T5DW02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 400×240(RGB) , WQVGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 108×64.8 mm |
| suprafaţă | |
| luminozitatea | |
| Raport de contrast | 1200:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 15/10 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/45/45 (Typ.)(CR≥200)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | CMOS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
