| PartNumber | LQ050T5DG02 |
| Marca | SHARP |
| mărimea | 5.0 |
| Aplicație | CNS |
| Rezoluţie | 400×240 |
| Compoziţie | LCM |
| Luminozitate | 600 |
| CR | |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ050T5DG02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 400(RGB)×240 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 108×64.8 mm |
| contur | 120.6×75.2 mm |
| suprafaţă | |
| luminozitatea | 600 cd/m² (Typ.) |
| Raport de contrast | |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | |
| unghi de vedere | |
| tip lampa | WLED |
| interfață de semnal | CMOS (1 ch, 6-bit) |
| rohs: | |
| aplicarea | CNS |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ050T1SX02 | SHARP | 5.0 | 1080×1920 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| A070VTN03.0 | AUO | 7.0 | 800×480 |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| CLAA043JE01CW | CPT | 4.3 | 480×272 |
| G141I1-L01 | Innolux | 14.1 | 1280×800 |
| HSD070IDW1-E11 | HannStar | 7.0 | 800×480 |
| LB048Q01-TD01 | LG Display | 4.8 | 240×257 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
