| PartNumber | PM065WX3 |
| Marca | E Ink |
| mărimea | 6.5 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 550 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | PVI |
| model de panou | PM065WX3 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 6.5 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 143.4×79.2 mm |
| contur | 155.2×89.4×6.1 mm |
| suprafaţă | Antiglare |
| luminozitatea | 550 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 15/25 (Typ.)(Tr/Td) |
| unghi de vedere | 75/75/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S14PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/3.3/9.5/17.0/-8.0V (Typ.)(VCC/VDD1/VDD2/VGG/VEE) |
| aplicarea | CNS |
