| PartNumber | LA050WQ1-TD01 |
| Marca | LG Display |
| mărimea | 5.0 |
| Aplicație | CNS |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 1100 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | LG Display |
| model de panou | LA050WQ1-TD01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 110.88×62.478 mm |
| contur | 124×75.2×8.3 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 1100 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193175% |
| timp de raspuns | 6/9 (Typ.)(Tr/Td) |
| unghi de vedere | 55/55/55/25 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/10.0V (Typ.)(DVDD/AVDD) |
| aplicarea | CNS |
