| PartNumber | PA050DT2 |
| Marca | E Ink |
| mărimea | 5.0 |
| Aplicație | CNS |
| Rezoluţie | 320×234 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 350:1 |
| Culori | Full color |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | PVI |
| model de panou | PA050DT2 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 320(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 102.72×74.53 mm |
| contur | 127.4×92.8×19 mm |
| suprafaţă | Antiglare |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Typ.) |
| culorile afișajului | Full color |
| timp de raspuns | 15/30 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 1 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | TFT Specific Analog RGB, 28 pins |
| tensiune de intrare | 12.0V (Typ.)(LCD+Backlight) |
| aplicarea | CNS |
