| PartNumber | PA050DS7N1 |
| Marca | E Ink |
| mărimea | 5.0 |
| Aplicație | CNS |
| Rezoluţie | 320×234 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 350:1 |
| Culori | Full color |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | PVI |
| model de panou | PA050DS7N1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 320(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 102.72×74.53 mm |
| contur | 127.4×92.8 mm |
| suprafaţă | Antiglare |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Typ.) |
| culorile afișajului | Full color |
| timp de raspuns | 15/30 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | TFT Specific Analog RGB, 20 pins |
| tensiune de intrare | 5.0/5.0/17.0/-15.0V (Typ.)(VCC/VDD/VGH/VGL) |
| aplicarea | CNS |
| PA050DS2T1 | E Ink | 5.0 | 320×234 |
| PA050DS4 | E Ink | 5.0 | 320×234 |
| PA050DS7 | E Ink | 5.0 | 320×234 |
| PA050DS7N1 | E Ink | 5.0 | 320×234 |
| PA050DT2 | E Ink | 5.0 | 320×234 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PA050XSG | E Ink | 5.0 | 320×234 |
| PA050XSH | E Ink | 5.0 | 320×234 |
| PA050XU4 | E Ink | 5.0 | 320×234 |
| AV094Z9M-N10 | BOE | 9.4 | 1920×480 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| FG0700G3DSSWBGL4 | Data Image | 7.0 | 800×480 |
| HSD070IDW1-D00 | HannStar | 7.0 | 800×480 |
| LA050WQ2-SD02 | LG Display | 5.0 | 480×240 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ064A5CG01 | SHARP | 6.4 | 480×234 |
| LQ065T5GG63 | SHARP | 6.5 | 400×234 |
| LQ080Y5CGQ1 | SHARP | 8.0 | 800×480 |
