| PartNumber | PW065XS1 |
| Marca | E Ink |
| mărimea | 6.5 |
| Aplicație | CNS |
| Rezoluţie | 400×234 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 350:1 |
| Culori | Full color |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | PVI |
| model de panou | PW065XS1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 6.5 inch |
| rezoluţie | 400(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 143.4×79.326 mm |
| contur | 155.2×89.6×7.9 mm |
| suprafaţă | Antiglare |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Typ.) |
| culorile afișajului | Full color |
| timp de raspuns | 15/25 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | TFT Specific Analog RGB, 30 pins |
| tensiune de intrare | 3.3/3.3/5.0/15.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| aplicarea | CNS |
