| PartNumber | LB070WV7-TL01 |
| Marca | LG Display |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LB070WV7-TL01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 152.4×91.44 mm |
| contur | 164.4×102.2×14.3 mm |
| suprafaţă | Antiglare |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 7/18 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS, 40 pins |
| tensiune de intrare | 8.0V (Typ.) |
| aplicarea | CNS |
| LB070WQ4-TM01 | LG Display | 7.0 | 480×234 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD03 | LG Display | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV4-TD02 | LG Display | 7.0 | 800×480 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| AV094Z9M-N10 | BOE | 9.4 | 1920×480 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
| L5F30442T15 | Epson | 6.5 | 800×480 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
