| PartNumber | C090EAN01.1 |
| Marca | AUO |
| mărimea | 9.0 |
| Aplicație | CNS |
| Rezoluţie | 1280×720 |
| Compoziţie | LCM |
| Luminozitate | 680 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | C090EAN01.1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 9.0 inch |
| rezoluţie | 1280(RGB)×720 , WXGA |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 198.72×111.78 mm |
| contur | 210×126.8 mm |
| suprafaţă | Antiglare |
| luminozitatea | 680 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 15/15 (Max.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S3PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3/3.3V (Typ.)(VDD/VDDA) |
| aplicarea | CNS |
