| PartNumber | LTE430WQ-F07 |
| Marca | Samsung |
| mărimea | 4.3 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SAMSUNG |
| model de panou | LTE430WQ-F07 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480×272(RGB) , WQVGA |
| modul de afișare | TN, Normally White, TMR |
| Zonă activă | 95.04×53.856 mm |
| contur | 105.5×67.2×4.15 mm |
| suprafaţă | |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 400 : 1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 5/25 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.)(VDD) |
| aplicarea | PND |
| 990000475P | TPO | 4.3 | 800×480 |
| AA043MA01 | Mitsubishi | 4.3 | 800×480 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
| LS043K1SX02 | SHARP | 4.3 | 720×1280 |
| LTE430WQ-F07 | Samsung | 4.3 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| TD043MGEB1 | TPO | 4.3 | 800×480 |
| 35QVW1T | SII | 3.5 | 320×240 |
| 43WQW3T | SII | 4.3 | 480×272 |
| A047FW01 V0 | AUO | 4.7 | 480×272 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| AT043TN13 | Innolux | 4.3 | 480×272 |
| DLC0500HZG-T-8 | Other | 5.0 | 800×480 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| TS40WD2B-03 | Other | 4.0 | 480×272 |
