| PartNumber | AA043MA01 |
| Marca | Mitsubishi |
| mărimea | 4.3 |
| Aplicație | IA |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 400:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | Mitsubishi |
| model de panou | AA043MA01 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 93×55.8 mm |
| contur | 103×67.5×5.8 mm |
| suprafaţă | Clear, Hard coating (2H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| timp de raspuns | 5/20 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/65/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2 stringsWLEDWithout Driver |
| interfață de semnal | CMOS (1 ch, 6/8-bit), 45 pins |
| tensiune de intrare | 3.3V (Typ.)(VCC) |
| aplicarea | IA |
