| PartNumber | C043FW01 V0 |
| Marca | AUO |
| mărimea | 4.3 |
| Aplicație | CNS |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 700 |
| CR | 400:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | C043FW01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 94.32×52.65 mm |
| contur | 105.3×65.6 mm |
| suprafaţă | |
| luminozitatea | 700 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Min.) |
| culorile afișajului | 16.2M (6-bit + FRC) |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
| 990000475P | TPO | 4.3 | 800×480 |
| AM480272H3TMQW-W2H | AMPIRE | 4.3 | 480×272 |
| C043FW01 V0 | AUO | 4.3 | 480×234 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03 | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01D | SHARP | 4.3 | 480×800 |
| LS043T1LX01A | SHARP | 4.3 | 540×960 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C070VW04 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| FG0700K5DSSWBG01 | Data Image | 7.0 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LB048Q01-TD01 | LG Display | 4.8 | 240×257 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
