| PartNumber | A047FW01 V0 |
| Marca | AUO |
| mărimea | 4.7 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 380 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A047FW01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.7 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 103.68×58.752 mm |
| contur | 114.24×72.88×5.7 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 380 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 15/20 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S1P+6S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 45 pins |
| tensiune de intrare | 3.3/1.8V (Typ.)(VDD/VDDIO) |
| aplicarea | PND |
