| PartNumber | A040FL01 V2 |
| Marca | AUO |
| mărimea | 4.0 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A040FL01 V2 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.0 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | ATR-MVA, Normally Black, Transflective |
| Zonă activă | 87.84×49.776 mm |
| contur | 98.3×62.6 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.)(Transmissive) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 20/20 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 8S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| tensiune de intrare | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplicarea | PND |
