| PartNumber | PD035QX1 |
| Marca | E Ink |
| mărimea | 3.5 |
| Aplicație | PND |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | CPU/RGB/SPI |
| marca panoului | PVI |
| model de panou | PD035QX1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 53.64×71.52 mm |
| contur | 64×85×3.8 mm |
| suprafaţă | Antiglare |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 15/25 (Typ.)(Tr/Td) |
| unghi de vedere | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S3PWLEDWithout Driver |
| interfață de semnal | CPU/RGB/SPI, 50 pins |
| rohs: | |
| aplicarea | PND |
