| PartNumber | 35QVW1H |
| Marca | SII |
| mărimea | 3.5 |
| Aplicație | PND |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SII |
| model de panou | 35QVW1H |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 70.08×52.56 mm |
| contur | 76.9×63.9×3.4 mm |
| suprafaţă | Clear, Hard coating |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193160% |
| timp de raspuns | 15/35 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 6S1PWLED |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| aplicarea | PND |
