| PartNumber | GCX123AKQ-E |
| Marca | JDI |
| mărimea | 3.5 |
| Aplicație | CNS |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 620 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | JDI |
| model de panou | GCX123AKQ-E |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 53.28×71.04 mm |
| contur | 81.6×95.57×25.3 mm |
| suprafaţă | |
| luminozitatea | 620 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193165% |
| timp de raspuns | 53 (Max.)(Tr+Td) |
| unghi de vedere | |
| frecvență | 60Hz |
| tip lampa | 2S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
