| PartNumber | LTV350QV-F09 |
| Marca | Samsung |
| mărimea | 3.5 |
| Aplicație | DSC |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 320 |
| CR | 300:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SAMSUNG |
| model de panou | LTV350QV-F09 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, TMR |
| Zonă activă | 70.08×52.56 mm |
| contur | 76.9×63.9×4.45 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 320 cd/m² (Typ.) |
| Raport de contrast | 300 : 1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| tensiune de intrare | 3.3/4.9/18.0/-10.0V (Typ.)(VCC/DDVDH/VGH/VGL) |
| aplicarea | DSC |
