| PartNumber | TM035NDH04 |
| Marca | Tianma |
| mărimea | 3.5 |
| Aplicație | HHP |
| Rezoluţie | 272×480 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 65K/262K |
| Iluminare de fundal | WLED |
| Interfață | CPU |
| marca panoului | TIANMA |
| model de panou | TM035NDH04 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 272(RGB)×480 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 43.86×77.4 mm |
| contur | 50.86×87.98×2.5 mm |
| suprafaţă | Antiglare |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 65K/262K , CIE193150% |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| unghi de vedere | 60/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 1S6PWLEDWithout Driver |
| interfață de semnal | CPU, 41 pins |
| tensiune de intrare | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| aplicarea | HHP |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03 | Tianma | 3.5 | 320×240 |
| TM035KDH03-36 | Tianma | 3.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| TM035PDZ00 | Tianma | 3.5 | 320×480 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
| 20QVF0H | SII | 2.0 | 240×320 |
| 24QVW2H | SII | 2.4 | 240×320 |
| 35HVE1H | SII | 3.5 | 320×480 |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| AM-240320-022F | Other | 2.2 | 240×320 |
| AM-320240LATNQW-T00H-F | AMPIRE | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ035Q7DB05 | SHARP | 3.5 | 240×320 |
| LQ039Q2DS51 | SHARP | 3.9 | 320×240 |
| TX09D40VM3CBA | KOE | 3.5 | 240×320 |
