| PartNumber | LQ043T3DX0F |
| Marca | SHARP |
| mărimea | 4.3 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ043T3DX0F |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 95.04×53.856 mm |
| contur | 105.5×67.2 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 30/30 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 60 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PND |
