| PartNumber | LQ043T1LX01A |
| Marca | SHARP |
| mărimea | 4.3 |
| Aplicație | MPH |
| Rezoluţie | 540×960 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MDDI/MIPI |
| marca panoului | SHARP |
| model de panou | LQ043T1LX01A |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 540(RGB)×960 , qHD |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 53.46×95.04 mm |
| contur | 58.54×105.7 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 35 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 10S1PWLEDWithout Driver |
| interfață de semnal | MDDI/MIPI, 25 pins |
| tensiune de intrare | 1.8/3.1V (Typ.)(IOVDD/AVDD) |
| aplicarea | MPH |
