| PartNumber | LS041Y3LW01 |
| Marca | SHARP |
| mărimea | 4.1 |
| Aplicație | MPH |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 385 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | FlatLink3G |
| marca panoului | SHARP |
| model de panou | LS041Y3LW01 |
| tip panou | CG-Silicon , LCM |
| dimensiunea panoului | 4.1 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | Normally Black, Transmissive |
| Zonă activă | 90×54 mm |
| contur | 106.6×64.2 mm |
| suprafaţă | |
| luminozitatea | 385 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 22/12 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | FlatLink3G, 31 pins |
| tensiune de intrare | 2.75/1.8V (Typ.)(VDD/VDD1) |
| aplicarea | MPH |
