| PartNumber | LQ043T1DH01 |
| Marca | SHARP |
| mărimea | 4.3 |
| Aplicație | PND |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 360 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ043T1DH01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480×272(RGB) , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 95.04×53.86 mm |
| contur | 105.5×67.2×5.3 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 360 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193148% |
| timp de raspuns | 30/30 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| tensiune de intrare | 1.8/3.3/2.8V (Typ.)(VDDIO/VCI) |
| aplicarea | PND |
| LQ043T1DG03 | SHARP | 4.3 | 480×272 |
| LQ043T1DG04 | SHARP | 4.3 | 480×272 |
| LQ043T1DH04 | SHARP | 4.3 | 480×272 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| 37WVF0H | SII | 3.7 | 480×800 |
| A043FW02 V8 | AUO | 4.3 | 480×272 |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| DLC0430LZG-6 | Other | 4.3 | 480×272 |
| LB043WQ1-TD01 | LG Display | 4.3 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
