| PartNumber | H020HD01 V0 |
| Marca | AUO |
| mărimea | 2.0 |
| Aplicație | MPH |
| Rezoluţie | 176×220 |
| Compoziţie | OLED |
| Luminozitate | 105 |
| CR | 10000:1 |
| Culori | 65K/262K |
| Iluminare de fundal | self |
| Interfață | CPU |
| marca panoului | AUO |
| model de panou | H020HD01 V0 |
| tip panou | AM-OLED , OLED |
| dimensiunea panoului | 2.0 inch |
| rezoluţie | 176(RGB)×220 , QCIF+ |
| Zonă activă | 31.152×38.94 mm |
| contur | 39.52×53.2 mm |
| suprafaţă | Hard coating |
| luminozitatea | 105 cd/m² (Typ.) |
| Raport de contrast | 10000 : 1 (Typ.) |
| culorile afișajului | 65K/262K (6-bit), CIE193168% |
| unghi de vedere | 30/30/30/30 (Typ.)(CR≥2)(L/R/U/D) |
| driver ic | Built-in uPD161621 + uPD161644 |
| interfață de semnal | CPU, 34 pins |
| tensiune de intrare | 3.3/-7.0V (Typ.)(VCC/VSS) |
| aplicarea | MPH |
