| PartNumber | ACX450AKN-7 |
| Marca | JDI |
| mărimea | 5.0 |
| Aplicație | MPH |
| Rezoluţie | 1080×1920 |
| Compoziţie | LCM |
| Luminozitate | 485 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | JDI |
| model de panou | ACX450AKN-7 |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 1080(RGB)×1920 , FHD |
| modul de afișare | Normally Black, Transmissive |
| Zonă activă | 61.884×110.016 mm |
| contur | 64.284×118.8×1.58 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 485 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193171% |
| timp de raspuns | 35 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S2PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 31 pins |
| tensiune de intrare | +5.0/-5.0/1.8V (Typ.)(AVDD+/AVDD-/IOVDD) |
| aplicarea | MPH |
