| PartNumber | LD050WQ1-TD02 |
| Marca | LG Display |
| mărimea | 5.0 |
| Aplicație | DPF |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| marca panoului | LG Display |
| model de panou | LD050WQ1-TD02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 480×272(RGB) , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 110.88×62.832 mm |
| suprafaţă | |
| luminozitatea | |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Dithering), CIE193148% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/65/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | WLED |
| aplicarea | DPF |
