| PartNumber | LTE700WQ-F05 |
| Marca | Samsung |
| mărimea | 7.0 |
| Aplicație | DPF |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | SAMSUNG |
| model de panou | LTE700WQ-F05 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 480×234(RGB) |
| modul de afișare | TN, Normally White, TMR |
| Zonă activă | 154.08×86.58 mm |
| contur | 166×100×7.2 mm |
| suprafaţă | |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 500 : 1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 13/17 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 2.5/3.3V (Typ.)(VDD) |
| aplicarea | DPF |
