| PartNumber | M070SW46 R0 |
| Marca | IVO |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 1200×1920 |
| Compoziţie | LCM |
| Luminozitate | 380 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | IVO |
| model de panou | M070SW46 R0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1200(RGB)×1920 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 94.5×151.2 mm |
| contur | 104×161.37×3.59 mm |
| suprafaţă | Antiglare, Hard coating (3H), Antireflection |
| luminozitatea | 380 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193160% |
| timp de raspuns | 30 (Max.)(Tr+Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥100)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | MIPI (4 data lanes), 31 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
| 70WVW5A | SII | 7.0 | 800×480 |
| HV070WS1-1E2 | HYDIS | 7.0 | 1024×600 |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LD070WS2-SL06 | LG Display | 7.0 | 1024×600 |
| LTA070B0C0A | TOSHIBA | 7.0 | 480×234 |
| LTL070NL02-W02 | Samsung | 7.0 | 1024×600 |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| M070SWP1 R4 | IVO | 7.0 | 800×480 |
| M070SWP1 R5 | IVO | 7.0 | 800×480 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| BP096WX7-100 | BOE | 9.6 | 800×1280 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HSD101PWW1-F00 | HannStar | 10.1 | 1280×800 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-104 | Samsung | 10.1 | 1280×800 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
