| PartNumber | BP096WX7-100 |
| Marca | BOE |
| mărimea | 9.6 |
| Aplicație | PAD |
| Rezoluţie | 800×1280 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | MIPI |
| marca panoului | BOE |
| model de panou | BP096WX7-100 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 9.6 inch |
| rezoluţie | 800(RGB)×1280 , WXGA |
| modul de afișare | ADS, Normally Black, Transmissive |
| Zonă activă | 129×206.4 mm |
| contur | 133.4×213.85 mm |
| suprafaţă | |
| adâncimea sticlei | 0.25+0.25 mm |
| transmisivitatea | 5.6% (Typ.)(with Polarizer) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| driver ic | Built-in NT51017 |
| interfață de semnal | MIPI (4 data lanes), 40 pins |
| aplicarea | PAD |
