| PartNumber | BP070HD1-100 |
| Marca | BOE |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 720×1280 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | BOE |
| model de panou | BP070HD1-100 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 87.264×155.136 mm |
| contur | 91.264×164.736 mm |
| suprafaţă | Hard coating (2H) |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193155% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S3PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 34 pins |
| tensiune de intrare | 1.8/3.3V (Typ.)(VCC/VDD) |
| aplicarea | PAD |
