| PartNumber | VVF07H119A90 |
| Marca | Panasonic |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 800×1280 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1000:1 |
| Culori | 262K |
| Iluminare de fundal | No B/L |
| Interfață | MIPI |
| marca panoului | Panasonic |
| model de panou | VVF07H119A90 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×1280 , WXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 94.2×150.72 mm |
| suprafaţă | Hard coating |
| adâncimea sticlei | 0.25+0.25 mm |
| transmisivitatea | 4.5% (Typ.)(with Polarizer) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193160% |
| timp de raspuns | 30 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | MIPI (4 data lanes), 34 pins |
| tensiune de intrare | 1.8/3.3V (Typ.)(VCC/VDD) |
| aplicarea | PAD |
| 70WVW1A | SII | 7.0 | 800×480 |
| A070VW04 V4 | AUO | 7.0 | 800×480 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| CLAA070MA0ACW | CPT | 7.0 | 800×600 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| VVF07H119A90 | Panasonic | 7.0 | 800×1280 |
| B079XAN02.0 CELL | AUO | 7.9 | 768×1024 |
| B080XAT01.1 | AUO | 7.9 | 768×1024 |
| HJ080NA-04L | Innolux | 8.0 | 1024×768 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LQ097L1JY01 | SHARP | 9.7 | 2048×1536 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| TFT08925601600 | SEBO | 8.9 | 2560×1600 |
