| PartNumber | LP101WH4-SLAA |
| Marca | LG Display |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 1366×768 |
| Compoziţie | Assembly |
| Luminozitate | 315 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LP101WH4-SLAA |
| tip panou | a-Si TFT-LCD , Assembly |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| Zonă activă | 222.52×125.11 mm |
| contur | 254.3×158×5.45 mm |
| suprafaţă | Anti Fingerprint, Hard coating (8H) |
| luminozitatea | 315 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (1 ch, 8-bit), 39 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
