| PartNumber | LP101WX2-SLA1 |
| Marca | LG Display |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 1280×800 |
| Compoziţie | Assembly |
| Luminozitate | 360 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LP101WX2-SLA1 |
| tip panou | a-Si TFT-LCD , Assembly |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| Zonă activă | 216.96×135.6 mm |
| contur | 257.2×175.4×5.9 mm |
| suprafaţă | Anti Fingerprint |
| luminozitatea | 360 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
