| PartNumber | BP101WX1-206 |
| Marca | BOE |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 330 |
| CR | 600:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | BOE |
| model de panou | BP101WX1-206 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | ADS, Normally Black, Transmissive |
| Zonă activă | 216.96×135.6 mm |
| contur | 228.6×149.2×4.59 mm |
| suprafaţă | Hard coating (3H), Antireflection |
| luminozitatea | 330 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Min.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193150% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| HT12X21-351 | HYDIS | 12.1 | 1024×768 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
