| PartNumber | B116XAT03.1 |
| Marca | AUO |
| mărimea | 11.6 |
| Aplicație | PAD |
| Rezoluţie | 1366×768 |
| Compoziţie | Assembly |
| Luminozitate | 350 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B116XAT03.1 |
| tip panou | a-Si TFT-LCD , Assembly |
| dimensiunea panoului | 11.6 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| Zonă activă | 256.125×144 mm |
| contur | 288.8×176.8×8.43 mm |
| suprafaţă | Hard coating (8H) |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| B116XTB01.0 | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V0 | AUO | 11.6 | 1366×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| HT10X21-311 | HYDIS | 10.4 | 1024×768 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
