| PartNumber | VVX07F023B00 |
| Marca | Panasonic |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 1200×1920 |
| Compoziţie | LCM |
| Luminozitate | 430 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | Panasonic |
| model de panou | VVX07F023B00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1200(RGB)×1920 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 94.5×151.2 mm |
| contur | 104×161.37×3.9 mm |
| suprafaţă | Antireflection |
| luminozitatea | 430 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193160% |
| timp de raspuns | 30 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | MIPI (4 data lanes), 31 pins |
| tensiune de intrare | 3.4V (Typ.) |
| aplicarea | PAD |
