| PartNumber | VVX07F015M00 |
| Marca | Panasonic |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 1200×1920 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 1200:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | Panasonic |
| model de panou | VVX07F015M00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1200(RGB)×1920 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 94.5×151.2 mm |
| contur | 104.52×161.87×2.4 mm |
| suprafaţă | Hard coating |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 1200:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 30 (Max.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4S6PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 40 pins |
| tensiune de intrare | 1.8/3.7V (Typ.)(VCC/VDD) |
| aplicarea | PAD |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| AT070TN92 V.4 | Innolux | 7.0 | 800×480 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| CLAA070ND36CW | CPT | 7.0 | 1024×600 |
| G070VW01 V1 | AUO | 7.0 | 800×480 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| LD070WS1-SL02 | LG Display | 7.0 | 1024×600 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
| VVX07F015M00 | Panasonic | 7.0 | 1200×1920 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HT12X21-240 | HYDIS | 12.1 | 1024×768 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| LP097X02-SLAA | LG Display | 9.7 | 1024×768 |
| LTN097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| VVX07H005A10 | Panasonic | 7.0 | 800×1280 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
