| PartNumber | TM070WA-22L06 |
| Marca | SANYO |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 100:1 |
| Culori | |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | TORISAN |
| model de panou | TM070WA-22L06 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 480(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 154.08×87.05 mm |
| contur | 167×102 mm |
| suprafaţă | Antiglare |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 100:1 (Min.) |
| culorile afișajului | |
| timp de raspuns | 30/20 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/30/40 (Max.)(CR≥5)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFL |
| interfață de semnal | TFT Specific Analog RGB, 24 pins |
| tensiune de intrare | 5.3/15.0/-14V (Typ.)(VSH/VGH/VGL) |
| aplicarea | CNS |
